Tool Steel

Overview of Tool Steel

Tool steel is a high-performance carbon and alloy steel specifically engineered for the manufacture of cutting tools, dies, moulds, punches, machine tooling and wear-resistant components. By combining carefully controlled levels of carbon with alloying elements such as chromium, molybdenum, vanadium, tungsten, manganese and silicon, tool steel delivers exceptional hardness, wear resistance, toughness, dimensional stability and heat resistance.

Unlike conventional engineering steels, tool steels are designed to retain their hardness and strength under demanding operating conditions, including repeated impact loading, abrasive wear and elevated temperatures. Following appropriate heat treatment, tool steels achieve excellent edge retention, compressive strength and resistance to deformation, making them suitable for precision tooling and long production runs.

Tool steel is extensively used throughout the tooling, aerospace, automotive, defence, plastics, oil and gas, manufacturing, construction, metalworking, forging and precision engineering industries where reliable performance and extended service life are essential.

Chargentum supplies premium-quality Ground Flat Stock Tool Steel together with H13, D2, O1 and P20 Tool Steel Round Bars in a comprehensive range of sizes for customers across the UK. Materials are supplied with full mill certification and are suitable for machining, heat treatment and precision engineering applications.

Tool Steel Types

Product	DIN Grade	Tool Steel Type	Typical Applications
Ground Flat Stock Tool Steel – 500mm	Various Tool Steel Grades	Precision Ground Tool Steel	Dies, Jigs, Fixtures, Machine Components, General Toolmaking
H13 Tool Steel Round Bar	DIN 1.2344	Hot Work Tool Steel	Die Casting Dies, Extrusion Dies, Forging Tools, Hot Shear Blades
D2 Tool Steel Round Bar	DIN 1.2379	High Carbon High Chromium Cold Work Tool Steel	Blanking Dies, Punches, Industrial Knives, Wear Parts
O1 Tool Steel Round Bar	DIN 1.2510	Oil Hardening Cold Work Tool Steel	Cutting Tools, Gauges, Bushes, Punches, Precision Tools
P20 Tool Steel Round Bar	DIN 1.2311	Plastic Mould Tool Steel	Injection Moulds, Plastic Dies, Blow Moulds, Tooling Plates

Notes:

Available with full mill test certification (EN 10204 3.1).
Excellent wear resistance for demanding industrial applications.
High dimensional stability after heat treatment.
Suitable for machining, grinding and polishing.
Grades available for both hot work and cold work tooling.
Precision ground and machined finishes available.
Excellent toughness and edge retention.
Good resistance to thermal fatigue and heat checking (H13).
Nationwide UK delivery.

Standard Grades

Chargentum supplies the UK’s most widely specified Tool Steel grades for precision machining, mould tooling, die manufacture, metal forming and industrial engineering applications.

Grade	DIN Designation	Typical Hardness (HRC)*	Primary Applications
Ground Flat Stock Tool Steel	Various	Supplied Annealed	General Toolmaking, Jigs & Fixtures
H13	DIN 1.2344	44–52 HRC	Hot Work Dies, Forging & Die Casting
D2	DIN 1.2379	58–62 HRC	Cold Work Dies, Knives, Punches
O1	DIN 1.2510	57–62 HRC	Precision Cutting Tools & Gauges
P20	DIN 1.2311	28–34 HRC (Pre-Hardened)	Plastic Injection Moulds & Tooling

*Typical hardness after appropriate heat treatment unless supplied pre-hardened.

Chemical Composition (Typical % by Mass)

Element	H13 (1.2344)	D2 (1.2379)	O1 (1.2510)	P20 (1.2311)	Function
Carbon (C)	0.37–0.42	1.45–1.60	0.85–1.00	0.35–0.45	Hardness & Strength
Silicon (Si)	0.80–1.20	0.10–0.60	0.10–0.40	0.20–0.40	Deoxidation
Manganese (Mn)	0.20–0.50	0.20–0.60	1.00–1.40	1.30–1.60	Toughness
Chromium (Cr)	4.80–5.50	11.00–13.00	0.40–0.70	1.80–2.10	Wear & Corrosion Resistance
Molybdenum (Mo)	1.20–1.50	0.70–1.20	Trace	0.15–0.30	Hardenability
Vanadium (V)	0.80–1.20	0.70–1.10	0.10–0.25	—	Grain Refinement & Wear Resistance
Nickel (Ni)	—	—	—	Up to 0.30	Toughness
Sulphur (S)	≤0.03	≤0.03	≤0.03	≤0.03	Controlled Residual
Phosphorus (P)	≤0.03	≤0.03	≤0.03	≤0.03	Controlled Residual

Mechanical Properties

Property	H13	D2	O1	P20	Notes
Hardness	44–52 HRC	58–62 HRC	57–62 HRC	28–34 HRC	Typical Supply/Heat Treated Condition
Density	7,800–7,850 kg/m³	7,700 kg/m³	7,850 kg/m³	7,850 kg/m³	Typical
Modulus of Elasticity	210,000 MPa	210,000 MPa	210,000 MPa	210,000 MPa	Material Stiffness
Thermal Conductivity	24–28 W/mK	20–24 W/mK	36–42 W/mK	29–32 W/mK	Approximate
Compressive Strength	Excellent	Excellent	Very Good	Good	Tooling Performance
Wear Resistance	Very Good	Excellent	Excellent	Good	Service Life
Toughness	Excellent	Good	Very Good	Excellent	Impact Resistance

Delivery Conditions

Condition	Description
Annealed	Standard machining condition
Pre-Hardened	Standard for P20 Tool Steel
Hot Rolled	Mill finish available
Peeled	Improved dimensional accuracy
Turned	Machined finish
Ground	Precision ground finish
Precision Ground	Tight tolerance applications
Cut to Size	Available on request
Ultrasonically Tested	Available for critical applications

Physical Properties

Property	Value	Notes
Density	7,700–7,850 kg/m³	Depending on grade
Modulus of Elasticity	210,000 MPa	Typical
Thermal Expansion	10.5–12.5 ×10⁻⁶ /°C	Approximate
Thermal Conductivity	20–42 W/mK	Grade dependent
Electrical Conductivity	5–10% IACS	Approximate
Melting Range	1,370–1,480°C	Grade dependent

Standards & Specifications

Grade	DIN	EN Equivalent	AISI Equivalent	Typical Application
Ground Flat Stock	Various	Various	Various	General Toolmaking
H13	1.2344	X40CrMoV5-1	H13	Hot Work Tooling
D2	1.2379	X153CrMoV12	D2	Cold Work Tooling
O1	1.2510	100MnCrW4	O1	Oil Hardening Tool Steel
P20	1.2311	40CrMnMo7	P20	Plastic Mould Tool Steel

Heat Treatment Information

Process	H13	D2	O1	P20	Purpose
Annealing	840–870°C	850–900°C	760–790°C	710–760°C	Improve Machinability
Stress Relieving	600–650°C	600–650°C	650°C	550–650°C	Reduce Residual Stress
Hardening	1,010–1,030°C	1,020–1,040°C	780–820°C	Usually Supplied Pre-Hardened	Increase Hardness
Quenching	Air	Air/Oil	Oil	—	Controlled Cooling
Tempering	540–650°C	150–550°C	150–300°C	500–600°C (If Required)	Improve Toughness & Stability

This technical data provides a general engineering guide. Actual properties may vary depending on the manufacturing process, heat treatment condition and applicable material standards. Full mill certification and material test reports are available upon request with all Chargentum Tool Steel products.

METAL TYPES & APPLICATIONS

Ground Flat Stock Tool Steel – 500mm

Ground Flat Stock Tool Steel is supplied in precision-ground rectangular sections with consistent thickness and width tolerances. All sizes below are based on standard 500mm lengths and calculated using typical tool steel density (~7,850 kg/m³).

Chargentum supplies precision Ground Flat Stock Tool Steel in a wide range of thicknesses and widths, all manufactured to strict dimensional tolerances for high-performance toolmaking and engineering applications.

All material is supplied in standard 500mm lengths with precision-ground surfaces, ensuring excellent machinability, stability, and accuracy during fabrication.

Available with full mill certification, and nationwide UK delivery for toolmaking, mould manufacturing, and precision engineering industries.

This table is designed for toolmakers, machinists, and engineers requiring accurate weight estimation and material selection for tooling and precision applications.

Thickness (mm)	Width (mm)	Length (mm)	Weight (kg/Piece)	Condition	Grade	Typical Application
3	10	500	0.12	Annealed	Ground Flat Stock	Shims, spacers
3	20	500	0.24	Annealed	Ground Flat Stock	Gauge plates
4	20	500	0.31	Annealed	Ground Flat Stock	Small tooling inserts
4	25	500	0.39	Annealed	Ground Flat Stock	Precision parts
5	25	500	0.49	Annealed	Ground Flat Stock	Tool components
5	30	500	0.59	Annealed	Ground Flat Stock	Machine parts
6	30	500	0.71	Annealed	Ground Flat Stock	Wear strips
6	40	500	0.94	Annealed	Ground Flat Stock	Fixtures
8	40	500	1.26	Annealed	Ground Flat Stock	Jigs
8	50	500	1.57	Annealed	Ground Flat Stock	Tool bases
10	40	500	1.57	Annealed	Ground Flat Stock	Small die sets
10	50	500	1.96	Annealed	Ground Flat Stock	Fixtures
10	60	500	2.36	Annealed	Ground Flat Stock	Machine tooling
12	50	500	2.36	Annealed	Ground Flat Stock	Tool holders
12	60	500	2.83	Annealed	Ground Flat Stock	Press tools
12	80	500	3.77	Annealed	Ground Flat Stock	Die components
16	50	500	3.14	Annealed	Ground Flat Stock	Heavy inserts
16	75	500	4.71	Annealed	Ground Flat Stock	Tooling blocks
16	100	500	6.28	Annealed	Ground Flat Stock	Mould bases
20	50	500	3.93	Annealed	Ground Flat Stock	Small dies
20	80	500	6.28	Annealed	Ground Flat Stock	Punch bases
20	100	500	7.85	Annealed	Ground Flat Stock	Die sets
25	80	500	7.85	Annealed	Ground Flat Stock	Tool plates
25	100	500	9.81	Annealed	Ground Flat Stock	Mould tooling
25	125	500	12.27	Annealed	Ground Flat Stock	Forming dies
30	100	500	11.78	Annealed	Ground Flat Stock	Machine bases
30	125	500	14.72	Annealed	Ground Flat Stock	Tooling blocks
30	150	500	17.66	Annealed	Ground Flat Stock	Precision dies
40	100	500	15.70	Annealed	Ground Flat Stock	Heavy tooling
40	150	500	23.55	Annealed	Ground Flat Stock	Mould components
40	200	500	31.40	Annealed	Ground Flat Stock	Industrial dies
50	150	500	29.43	Annealed	Ground Flat Stock	Large tooling
50	200	500	39.25	Annealed	Ground Flat Stock	Injection mould tools
50	250	500	49.06	Annealed	Ground Flat Stock	Press tool bases
60	200	500	47.10	Annealed	Ground Flat Stock	Heavy engineering
60	250	500	58.88	Annealed	Ground Flat Stock	Large mould blocks
75	200	500	58.88	Annealed	Ground Flat Stock	Structural tooling
75	250	500	73.60	Annealed	Ground Flat Stock	Heavy dies
75	300	500	88.31	Annealed	Ground Flat Stock	Industrial tooling
100	200	500	78.50	Annealed	Ground Flat Stock	Large machine tooling
100	250	500	98.13	Annealed	Ground Flat Stock	Heavy industrial tools
100	300	500	117.75	Annealed	Ground Flat Stock	Engineering systems

Buy Ground Flat Stock Tool Steel – 500mm

H13 Tool Steel Round Bars – DIN 1.2344

H13 Tool Steel (DIN 1.2344) is a high-performance hot work tool steel designed for applications involving extreme heat, thermal shock and continuous mechanical stress. It is widely used in die casting, forging, extrusion and high-temperature tooling due to its excellent combination of hot hardness, toughness and resistance to thermal fatigue.

This chromium–molybdenum–vanadium alloy steel maintains strength at elevated temperatures, making it ideal for tooling exposed to repeated heating and cooling cycles. H13 is one of the most widely used hot work tool steels in demanding industrial environments where tool life and reliability are critical.

Chargentum supplies premium H13 Tool Steel Round Bars across the UK in a full range of diameters hot work tooling, die casting and forging applications. All material supplied in annealed condition for machining or heat-treated condition upon request, with full mill certification, ensuring traceability and compliance with UK engineering standards.

Diameter (mm)	Weight (kg/m)	Length (mm)	Condition	Grade	Typical Application
20	2.47	3000–6000	Annealed	H13 (1.2344)	Small punches
25	3.85	3000–6000	Annealed	H13 (1.2344)	Tool inserts
30	5.55	3000–6000	Annealed	H13 (1.2344)	Die components
35	7.55	3000–6000	Annealed	H13 (1.2344)	Precision tooling
40	9.87	3000–6000	Annealed	H13 (1.2344)	Punches
45	12.49	3000–6000	Annealed	H13 (1.2344)	Hot work tools
50	15.42	3000–6000	Annealed	H13 (1.2344)	Forging dies
60	22.20	3000–6000	Annealed	H13 (1.2344)	Extrusion tooling
70	30.21	3000–6000	Annealed	H13 (1.2344)	Heavy tooling
80	39.46	3000–6000	Annealed	H13 (1.2344)	Industrial dies
90	49.94	3000–6000	Annealed	H13 (1.2344)	Die casting systems
100	61.65	3000–6000	Annealed	H13 (1.2344)	Heavy engineering tools
125	96.33	3000–6000	Annealed	H13 (1.2344)	Large die components
150	138.72	3000–6000	Annealed	H13 (1.2344)	High-temperature tooling
200	246.60	3000–6000	Annealed	H13 (1.2344)	Heavy-duty tooling

Buy H13 Tool Steel Round Bar – DIN 1.2344

D2 Tool Steel Round Bars – DIN 1.2379

D2 Tool Steel (DIN 1.2379) is a high-carbon, high-chromium cold work tool steel designed for exceptional wear resistance, high hardness and superior edge retention. It is widely used in industrial tooling applications where prolonged service life and resistance to abrasion are critical.

Due to its high chromium content, D2 offers excellent resistance to wear and deformation, making it ideal for blanking dies, cutting tools, forming tools and precision industrial components. It is an air-hardening steel, providing good dimensional stability during heat treatment and reducing distortion compared to oil-quenched grades.

Chargentum supplies premium D2 Tool Steel Round Bars across the UK in a full range of diameters for cold work tooling, cutting tools and high-wear industrial applications, supplied in annealed condition for machining, with full mill certification and traceability, ensuring consistent quality and compliance with UK engineering standards.

Diameter (mm)	Weight (kg/m)	Length (mm)	Condition	Grade	Typical Application
20	2.47	3000–6000	Annealed	D2 (1.2379)	Small punches
25	3.85	3000–6000	Annealed	D2 (1.2379)	Cutting inserts
30	5.55	3000–6000	Annealed	D2 (1.2379)	Precision dies
35	7.55	3000–6000	Annealed	D2 (1.2379)	Tool components
40	9.87	3000–6000	Annealed	D2 (1.2379)	Blanking dies
45	12.49	3000–6000	Annealed	D2 (1.2379)	Industrial knives
50	15.42	3000–6000	Annealed	D2 (1.2379)	Punch tools
55	18.66	3000–6000	Annealed	D2 (1.2379)	Wear parts
60	22.20	3000–6000	Annealed	D2 (1.2379)	Forming dies
65	26.05	3000–6000	Annealed	D2 (1.2379)	Slitting blades
70	30.21	3000–6000	Annealed	D2 (1.2379)	Heavy cutting tools
75	34.69	3000–6000	Annealed	D2 (1.2379)	Industrial tooling
80	39.46	3000–6000	Annealed	D2 (1.2379)	Wear-resistant parts
85	44.55	3000–6000	Annealed	D2 (1.2379)	Machine knives
90	49.94	3000–6000	Annealed	D2 (1.2379)	Tool systems
100	61.65	3000–6000	Annealed	D2 (1.2379)	Heavy-duty dies
110	74.59	3000–6000	Annealed	D2 (1.2379)	Industrial systems
125	96.33	3000–6000	Annealed	D2 (1.2379)	Large tooling blocks
140	120.87	3000–6000	Annealed	D2 (1.2379)	Press tools
150	138.72	3000–6000	Annealed	D2 (1.2379)	High wear systems
160	157.83	3000–6000	Annealed	D2 (1.2379)	Heavy engineering tools
180	199.78	3000–6000	Annealed	D2 (1.2379)	Industrial dies
200	246.60	3000–6000	Annealed	D2 (1.2379)	Large tooling systems
220	298.39	3000–6000	Annealed	D2 (1.2379)	Heavy duty components
250	385.31	3000–6000	Annealed	D2 (1.2379)	Large industrial tooling
300	554.85	3000–6000	Annealed	D2 (1.2379)	Forged tooling blocks

Buy D2 Tool Steel Round Bar – DIN 1.2379

O1 Tool Steel Round Bars – DIN 1.2510

O1 Tool Steel (DIN 1.2510) is an oil-hardening cold work tool steel known for its excellent machinability, good dimensional stability during heat treatment and strong wear resistance. It is widely used in precision tooling applications where accuracy, edge retention and controlled hardness are essential.

Compared to high-chromium steels like D2, O1 offers easier machining and better control during heat treatment, making it ideal for toolmakers producing gauges, cutting tools, punches and precision engineering components. Its oil quenching process helps minimise distortion and cracking, making it suitable for complex tooling shapes.

Chargentum supplies premium O1 Tool Steel Round Bars across the UK in a full range of diameters suitable for precision tooling, cutting tools and engineering applications, supplied in annealed condition for machining, with full mill certification and traceability to ensure consistent performance and compliance with UK engineering standards.

Diameter (mm)	Weight (kg/m)	Length (mm)	Condition	Grade	Typical Application
20	2.47	3000–6000	Annealed	O1 (1.2510)	Small punches
25	3.85	3000–6000	Annealed	O1 (1.2510)	Cutting tools
30	5.55	3000–6000	Annealed	O1 (1.2510)	Precision dies
35	7.55	3000–6000	Annealed	O1 (1.2510)	Tool inserts
40	9.87	3000–6000	Annealed	O1 (1.2510)	Gauge components
45	12.49	3000–6000	Annealed	O1 (1.2510)	Machine tooling
50	15.42	3000–6000	Annealed	O1 (1.2510)	Punch tools
55	18.66	3000–6000	Annealed	O1 (1.2510)	Precision gauges
60	22.20	3000–6000	Annealed	O1 (1.2510)	Cutting dies
65	26.05	3000–6000	Annealed	O1 (1.2510)	Industrial tooling
70	30.21	3000–6000	Annealed	O1 (1.2510)	Heavy tools
75	34.69	3000–6000	Annealed	O1 (1.2510)	Engineering components
80	39.46	3000–6000	Annealed	O1 (1.2510)	Wear parts
85	44.55	3000–6000	Annealed	O1 (1.2510)	Tool systems
90	49.94	3000–6000	Annealed	O1 (1.2510)	Precision tooling
100	61.65	3000–6000	Annealed	O1 (1.2510)	Heavy-duty tools
110	74.59	3000–6000	Annealed	O1 (1.2510)	Industrial systems
125	96.33	3000–6000	Annealed	O1 (1.2510)	Large tooling blocks
140	120.87	3000–6000	Annealed	O1 (1.2510)	Press tooling
150	138.72	3000–6000	Annealed	O1 (1.2510)	Heavy engineering tools
160	157.83	3000–6000	Annealed	O1 (1.2510)	Tooling systems
180	199.78	3000–6000	Annealed	O1 (1.2510)	Large dies
200	246.60	3000–6000	Annealed	O1 (1.2510)	Industrial tooling
220	298.39	3000–6000	Annealed	O1 (1.2510)	Heavy components
250	385.31	3000–6000	Annealed	O1 (1.2510)	Large industrial tooling

Buy O1 Tool Steel Round Bar – DIN 1.2510

P20 Tool Steel Round Bars – DIN 1.2311

P20 Tool Steel (DIN 1.2311) is a low-alloy mould steel widely used for plastic injection moulds, die casting mould bases and precision tooling applications. It is supplied in a pre-hardened condition, offering a balanced combination of machinability, toughness and moderate wear resistance without requiring additional heat treatment in most applications.

P20 is one of the most commonly used mould steels in the tooling and plastics industry due to its excellent machinability, good polishability and dimensional stability. It is particularly suited for large mould cavities, mould frames, and tooling components where consistent performance and reduced machining time are essential.

Chargentum supplies premium P20 Tool Steel Round Bars across the UK in a wide range of diameters for plastic mould making, tooling systems and engineering applications, supplied in pre-hardened condition, with full mill certification and traceability to ensure consistent quality and compliance with UK engineering standards.

Diameter (mm)	Weight (kg/m)	Length (mm)	Condition	Grade	Typical Application
20	2.47	3000–6000	Pre-hardened	P20 (1.2311)	Small mould inserts
25	3.85	3000–6000	Pre-hardened	P20 (1.2311)	Precision tooling
30	5.55	3000–6000	Pre-hardened	P20 (1.2311)	Mould cavities
35	7.55	3000–6000	Pre-hardened	P20 (1.2311)	Tool blocks
40	9.87	3000–6000	Pre-hardened	P20 (1.2311)	Injection mould parts
45	12.49	3000–6000	Pre-hardened	P20 (1.2311)	Mould bases
50	15.42	3000–6000	Pre-hardened	P20 (1.2311)	Plastic mould tooling
55	18.66	3000–6000	Pre-hardened	P20 (1.2311)	Die inserts
60	22.20	3000–6000	Pre-hardened	P20 (1.2311)	Large mould components
65	26.05	3000–6000	Pre-hardened	P20 (1.2311)	Industrial mould tools
70	30.21	3000–6000	Pre-hardened	P20 (1.2311)	Mould frames
75	34.69	3000–6000	Pre-hardened	P20 (1.2311)	Heavy mould tooling
80	39.46	3000–6000	Pre-hardened	P20 (1.2311)	Plastic injection systems
85	44.55	3000–6000	Pre-hardened	P20 (1.2311)	Engineering moulds
90	49.94	3000–6000	Pre-hardened	P20 (1.2311)	Mould tooling blocks
100	61.65	3000–6000	Pre-hardened	P20 (1.2311)	Large mould systems
110	74.59	3000–6000	Pre-hardened	P20 (1.2311)	Industrial mould bases
125	96.33	3000–6000	Pre-hardened	P20 (1.2311)	Heavy mould tooling
140	120.87	3000–6000	Pre-hardened	P20 (1.2311)	Large cavity moulds
150	138.72	3000–6000	Pre-hardened	P20 (1.2311)	Plastic mould systems
160	157.83	3000–6000	Pre-hardened	P20 (1.2311)	Engineering mould blocks
180	199.78	3000–6000	Pre-hardened	P20 (1.2311)	Heavy mould applications
200	246.60	3000–6000	Pre-hardened	P20 (1.2311)	Large industrial moulds
220	298.39	3000–6000	Pre-hardened	P20 (1.2311)	High-volume mould tooling
250	385.31	3000–6000	Pre-hardened	P20 (1.2311)	Heavy-duty mould systems
300	554.85	3000–6000	Pre-hardened	P20 (1.2311)	Large engineering mould blocks

Buy P20 Tool Steel Round Bar – DIN 1.2311

Download Full Tool Steel Datasheet

Download the complete technical datasheet for Tool steel including:

Download Full Tool Steel Datasheet

EXPLORE MORE ABOUT CHARGENTUM’S STRUCTURAL STEEL, ENGINEERING STEEL, ALLOY STEEL, PERFORATED SHEETS, SEAMLESS TUBES, TOOL STEEL, STAINLESS STEEL, BRASS, COPPER, ALUMINIUM, GREEN STEEL AND METAL GRADES & SPECIFICATIONS

Name	Provider	Purpose	Expiry	Type
__stripe_mid	Stripe	Fraud prevention and detection	1 year	HTTP
__stripe_sid	Stripe	Fraud prevention and detection	30 minutes	HTTP
_stripe_origination_cookie	Stripe	Payment processing security	Session	HTTP
m	Stripe	Fraud prevention — distinguishes humans from bots	2 years	HTTP
woocommerce_cart_hash	chargentum.com	Stores cart data hash	Session	HTTP
woocommerce_items_in_cart	chargentum.com	Tracks items in cart	Session	HTTP
wp_woocommerce_session_*	chargentum.com	WooCommerce session identifier	2 days	HTTP
wordpress_logged_in_*	chargentum.com	Identifies authenticated users	Session	HTTP
wordpress_sec_*	chargentum.com	WordPress security token	Session	HTTP
wordpress_test_cookie	chargentum.com	Tests if cookies are enabled	Session	HTTP
wp-settings-*	chargentum.com	Stores user preferences for WordPress admin	1 year	HTTP
nitro_*	getnitropack.com	Performance optimisation caching	30 days	HTTP

Name	Provider	Purpose	Expiry	Type
_ga	chargentum.com	Registers a unique ID to generate statistics on how visitors use the website (Google Analytics)	2 years	HTTP
_ga_*	chargentum.com	Google Analytics 4 session identifier	2 years	HTTP
_gid	chargentum.com	Registers a unique ID for a single-day visit (Google Analytics)	1 day	HTTP
_gat	chargentum.com	Used to throttle request rate (Google Analytics)	1 day	HTTP
_fbp	chargentum.com	Facebook pixel — tracks visits for ad targeting	3 months	HTTP
fr	chargentum.com	Facebook — used to deliver, measure and improve the relevancy of ads	3 months	HTTP
ads/ga-audiences	chargentum.com	Google Ads — used for remarketing	Session	Pixel

Tool Steel - Grades and Specifications

Overview of Tool Steel

Tool Steel Types

Notes:

Standard Grades

Chemical Composition (Typical % by Mass)

Mechanical Properties

Delivery Conditions

Physical Properties

Standards & Specifications

Heat Treatment Information

METAL TYPES & APPLICATIONS

Ground Flat Stock Tool Steel – 500mm

H13 Tool Steel Round Bars – DIN 1.2344

D2 Tool Steel Round Bars – DIN 1.2379

O1 Tool Steel Round Bars – DIN 1.2510

P20 Tool Steel Round Bars – DIN 1.2311

Download Full Tool Steel Datasheet

EXPLORE MORE ABOUT CHARGENTUM’S STRUCTURAL STEEL, ENGINEERING STEEL, ALLOY STEEL, PERFORATED SHEETS, SEAMLESS TUBES, TOOL STEEL, STAINLESS STEEL, BRASS, COPPER, ALUMINIUM, GREEN STEEL AND METAL GRADES & SPECIFICATIONS

Engineering Steel

Alloy Steel

Perforated Sheets

Seamless Tube

Stainless Steel

Brass

Copper

Alumunium

Green Steel

Metal Grades & Specification

Sourced only from certified manufacturers

Compliant with all British and industry standards

Dedicated to quality and reliable service

Tool Steel - Grades and Specifications

Overview of Tool Steel

Tool Steel Types

Notes:

Standard Grades

Chemical Composition (Typical % by Mass)

Mechanical Properties

Delivery Conditions

Physical Properties

Standards & Specifications

Heat Treatment Information

METAL TYPES & APPLICATIONS

Ground Flat Stock Tool Steel – 500mm

H13 Tool Steel Round Bars – DIN 1.2344

D2 Tool Steel Round Bars – DIN 1.2379

O1 Tool Steel Round Bars – DIN 1.2510

P20 Tool Steel Round Bars – DIN 1.2311

Download Full Tool Steel Datasheet

EXPLORE MORE ABOUT CHARGENTUM’S STRUCTURAL STEEL, ENGINEERING STEEL, ALLOY STEEL, PERFORATED SHEETS, SEAMLESS TUBES, TOOL STEEL, STAINLESS STEEL, BRASS, COPPER, ALUMINIUM, GREEN STEEL AND METAL GRADES & SPECIFICATIONS

Engineering Steel

Alloy Steel

Perforated Sheets

Seamless Tube

Tool Steel

Stainless Steel

Brass

Copper

Alumunium

Green Steel

Metal Grades & Specification

Sourced only from certified manufacturers

Compliant with all British and industry standards

Dedicated to quality and reliable service

Thank you

Thank you

Download Tool Steel PDF
